Gold Nanohelices: Computer model of Gold Nanohelices (L,R). The DNA origami structure is depicted in grey and the gold nanoparticles in yellow.

Gold Nanohelices (L/R) in Buffer, 30µl

Gold Nanohelices sind chirale, nanoskalige Marker die speziell für die Elektronen-Tomographie (ET) / Cryo-ET (CET) / 3DEM entwickelt wurden. Die Nanohelices werden in Lösung geliefert und reichen für die Beschichtung von mehr als 10 TEM-Grids.

Artikel für gruppiertes Produkt
Artikelname	Menge
Gold Nanohelices (L), Chiralitäts Marker, linksdrehende Chiralität, 30µl SN-01L
Gold Nanohelices (R), Chiralitäts Marker, rechtdrehende Chiralität, 30µl SN-01R

Produktdetails

Beschreibung

Gold Nanohelices - Chirality Tomography Markers
The Gold Nanohelices (L,R) are chiral nanoscale markers especially suited for 3D Tomography / Electron Microscopy (EM) / CryoEM. Our chiral markers show pure chirality (L or R), which can easily be detected with EM due to the high contrast and the precise arrangement of the gold nanoparticles.

The Gold Nanohelices (L,R) are fabricated with the DNA origami technique where gold nanoparticles (10nm) are arranged into nanoscale helices (helical pitch 57 nm; length 110 nm; diameter 34 nm).

In Solution:
The Nanohelices are delivered in buffer (keep at 4°C): 1x TE, 11mM MgCl2. The sample size is ~30µl which is enough for the preparation of more than 10 TEM grids.

Also available as mounted version: The samples are shipped ready to use on a TEM grid.

Reference:

DNA-based Self-Assembly of Chiral Plasmonic Nanostructures with Tailored Optical Response. Anton Kuzyk, Robert Schreiber, Zhiyuan Fan, Günther Pardatscher, Eva-Maria Roller, Alexander Högele, Friedrich C. Simmel, Alexander O. Govorov und Tim Liedl. Nature Volume 483 pp311-314 (2012)
