Kreuzgitter, Replica mit Latexkugeln

E80055

Die Latexkugeln haben einen Durchmesser von 0,216µm und das Gitter 2160 Linien/mm. Dieses Testobjekt eignet sich zur Doppelkalibrierung der Vergrößerung.
113,50 € 135,07 €

Produktdetails

Beschreibung



Latex Spheres On Grating Replica

The addition of Latex Spheres to the Grating Replica provides a double check of the accuracy of magnification calibration. It is particularly useful at higher magnifications where only a few squares of the replica pattern can be photographed together.

Note: The latex particles in this specimen have a diameter of 0.261 micron.

To use both the Replica and Latex Spheres for Magnification Calibration:

(1)  Calculate the magnification using the diffraction grating replica pattern by the  following formula:
Magnification = Distance in mm between limiting lines x 2,160 /
Number of spaces between limiting lines
(2)  Calculate the magnification by measuring the magnified image of the 0.262 micron diameter latex spheres,  applying the following formula:
Magnification = Diameter (mm) x 3831.4

(Measure as many latex spheres as possible and calculate the average diameter. Ignore any latex spheres which are distorted.)

Care of Grating Replica Specimen:

When not in use the replica should be kept in a dust-free atmosphere (as the same vial in which it is supplied).  NEVER TRY TO CLEAN IT.  Avoid bending or touching thereplica.  When viewing a replica specimen in the TEM always begin at low magnification, with one square of the supporting copper grid filling the EM screen, slowly increase the illumination to near maximum intensity (but not to cross-over) then reduce the level of the illumination and go to the desired magnification.  Repeat this procedure every time a new area of the replica is to be viewed.

Weitere Informationen

Weitere Informationen
Anwendung
TEM
Typ
Kalibrierstandards
Vergrößerung hohe Vergrößerung
Verpackungseinheit 1 Stück
