Vibratom 5100mz-Plus

E5100MZ-Plus

Das Präzisionsvibratom 5100mz-Plus ist perfekt geeignet für frische Schnittpräparate, deren Vitalität länger erhalten werden muss, z.B. für elektrophysiologische Feldaufnahmen. Der Benutzer kann mithilfe des anpassbaren Klingenhalters und der “optischen” Kalibriereinrichtung die z-Achsen Ablenkung der Klinge auf 2 µm kalibrieren. Eine minimale z-Achsen Ablenkung reduziert das “Rauschen” und minimiert Schäden an der Schnittoberfläche für eine höhere Vitalität der Zellen an der Schnittfläche.

Beschreibung

Features

Includes a z-axis calibration unit
Vibration speeds from 50 to 80Hz
Amplitudes from 0.5mm to 1.5mm
Fine control of the blade advance (min. 0.1mm/sec)
Set start and stop position of blade travel
Remote controls allowing for sterile use in culture hood
Ice water bath easily removed for cleaning
Optional cold light and magnifier for clear observation
Optional Peltier cooled bath

Specifications

Optimal Z-Axis Deflection	2.0µm (±0.1µm)
Opti-cal Vertical (Z-axis) Calibration Device	Included as standard
Blade Oscillation Frequency Range	50-80Hz
Frequency step size	5Hz
Blade Oscillation Amplitude (nominal)	Minimum: 0.5mm Maximum: 1.5mm
Amplitude Step Size (nominal)	0.5mm
Advance Speed Resolution During Slicing	0.1mm/sec
Cutting head advance speed:	Min: -2.0mm/sec (-1.00mm during slicing) Max: +2.0mm/sec (+1.00mm during slicing)
Bath table rise & fall speed	Max. 1.0mm/sec
Specimen Retraction as Blade Retracts	Yes
Section thickness step size	1µm
Max. (vertical) travel of bath table	19mm
Max. travel of cutting head	40mm
Max Specimen Size	33 x 50 x 19mm
Memory to Store Section Thickness	Yes
Multiple User Settings	8 different
Operating Modes	Manual or semi-automated Slice Window
Cooling Options	Ice bath or optional Model 7610A Tissue Bath Cooler
Dimensions	13.7" x 17.7 x 13.7" 350 x 450 x 350 mm
